OAuth2 Login and Resource Server with Spring Boot 3

In modern applications, securing APIs and web applications is a top priority. In this post, we’ll dive deep into how to implement OAuth2 Login and Resource Server with Spring Boot 3. You will learn how to:

  • Secure your frontend using OAuth2 login
  • Protect your backend APIs using the Resource Server setup

This implementation uses Spring Security 6 and Spring Boot 3, leveraging features like JWT decoding and user info endpoints.

OAuth2 Login and Resource Server with Spring Boot 3

📦 Project Setup

Use Spring Initializr or your favorite IDE to create a project with the following dependencies:

  • Spring Web
  • Spring Security
  • OAuth2 Client
  • OAuth2 Resource Server

Package structure:


com.kscodes.springboot.security.oauth2
│
├── config
│   ├── SecurityConfig.java
│
├── controller
│   ├── UserController.java
│
└── application.properties

🔧 OAuth2 Login Configuration

We’ll first configure OAuth2 login for a simple frontend page.

SecurityConfig.java (Login)


package com.kscodes.springboot.security.oauth2.config;

import org.springframework.context.annotation.Bean;
import org.springframework.security.config.annotation.web.builders.HttpSecurity;
import org.springframework.security.web.SecurityFilterChain;

public class SecurityConfig {

    @Bean
    public SecurityFilterChain securityFilterChain(HttpSecurity http) throws Exception {
        http
            .authorizeHttpRequests(auth -> auth
                .requestMatchers("/", "/public").permitAll()
                .anyRequest().authenticated()
            )
            .oauth2Login(); // Enables OAuth2 login flow

        return http.build();
    }
}

🛡️ Resource Server Configuration (JWT)

To enable resource server support, configure Spring Security to validate JWT tokens.

Modify SecurityConfig.java


@Bean
public SecurityFilterChain resourceServerSecurity(HttpSecurity http) throws Exception {
    http
        .authorizeHttpRequests(auth -> auth
            .requestMatchers("/api/**").authenticated()
            .anyRequest().permitAll()
        )
        .oauth2ResourceServer(oauth2 -> oauth2
            .jwt()
        );

    return http.build();
}

🧩 application.properties


# OAuth2 Login
spring.security.oauth2.client.registration.google.client-id=YOUR_GOOGLE_CLIENT_ID
spring.security.oauth2.client.registration.google.client-secret=YOUR_GOOGLE_CLIENT_SECRET
spring.security.oauth2.client.registration.google.scope=openid,email,profile

# JWT Resource Server
spring.security.oauth2.resourceserver.jwt.issuer-uri=https://accounts.google.com

Note: The issuer URI ensures that Spring decodes and validates tokens issued by the provider.

👨‍💻 Controller Example


package com.kscodes.springboot.security.oauth2.controller;

import org.springframework.security.core.annotation.AuthenticationPrincipal;
import org.springframework.security.oauth2.core.oidc.user.OidcUser;
import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RestController;

@RestController
public class UserController {

    @GetMapping("/api/user")
    public String getUser(@AuthenticationPrincipal OidcUser user) {
        return "Welcome, " + user.getFullName();
    }

    @GetMapping("/public")
    public String publicEndpoint() {
        return "This is a public page.";
    }
}

🌐 How OAuth2 Login and Resource Server Work Together

  • The OAuth2 Login flow authenticates the user and fetches user information from the provider (e.g., Google, GitHub).
  • The Resource Server protects API endpoints using JWT tokens. When an authenticated user makes a request, the backend validates the JWT before serving the request.

This combination of OAuth2 Login and Resource Server with Spring Boot 3 gives you a scalable, secure architecture that separates concerns effectively.

✅ Summary

In this post, we explored how to set up OAuth2 Login and Resource Server with Spring Boot 3 using com.kscodes.springboot.security.oauth2 as the package structure. You’ve learned to:

  • Configure OAuth2 login for user authentication
  • Protect API endpoints with a resource server and JWT
  • Handle secure user data using Spring Security
