In microservices architecture, multiple instances of a service often run to handle increased traffic. But how do clients decide which instance to call? This is where Spring Cloud LoadBalancer comes in β a lightweight, reactive, and pluggable solution for client-side load balancing. It replaces Netflix Ribbon and works perfectly with Spring Cloud + Eureka.
This post covers everything you need to get started with Spring Cloud LoadBalancer, including service discovery integration and custom load balancing strategies.
π§ What is Spring Cloud LoadBalancer?
Spring Cloud LoadBalancer is a library that allows you to implement client-side load balancing without needing Netflix Ribbon.
- π Integrates with Eureka and other service registries.
- π Works seamlessly with WebClient and RestTemplate.
- π Supports round-robin by default and allows customization.
π¦ Project Setup
Letβs say we have:
|
1 2 3 4 5 6 |
com.kscodes.springboot.microservice βββ client-service (uses LoadBalancer) βββ product-service (multiple instances) |
π§ Dependencies for client-service (pom.xml)
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 |
<dependencies> <dependency> <groupId>org.springframework.cloud</groupId> <artifactId>spring-cloud-starter-loadbalancer</artifactId> </dependency> <dependency> <groupId>org.springframework.cloud</groupId> <artifactId>spring-cloud-starter-netflix-eureka-client</artifactId> </dependency> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-webflux</artifactId> </dependency> </dependencies> |
βοΈ Enable Eureka in application.yml
|
1 2 3 4 5 6 7 8 9 10 |
spring: application: name: client-service eureka: client: service-url: defaultZone: http://localhost:8761/eureka |
Do the same in product-service, which will register multiple instances.
π§ͺ Create Multiple Instances of product-service
You can simulate this by running it on different ports:
application.yml for instance 1:
|
1 2 3 4 5 6 7 |
server: port: 8081 spring: application: name: product-service |
application.yml for instance 2:
|
1 2 3 4 5 6 7 |
server: port: 8082 spring: application: name: product-service |
π§βπ» Using Spring Cloud LoadBalancer with WebClient
β WebClient Configuration
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 |
package com.kscodes.springboot.microservice.clientservice.config; import org.springframework.cloud.client.loadbalancer.LoadBalanced; import org.springframework.context.annotation.Bean; import org.springframework.context.annotation.Configuration; import org.springframework.web.reactive.function.client.WebClient; @Configuration public class WebClientConfig { @Bean @LoadBalanced public WebClient.Builder loadBalancedWebClientBuilder() { return WebClient.builder(); } } |
β Calling the Service
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 |
package com.kscodes.springboot.microservice.clientservice.controller; import org.springframework.beans.factory.annotation.Autowired; import org.springframework.web.bind.annotation.GetMapping; import org.springframework.web.bind.annotation.RestController; import org.springframework.web.reactive.function.client.WebClient; @RestController public class ProductClientController { @Autowired private WebClient.Builder webClientBuilder; @GetMapping("/get-products") public String getProducts() { return webClientBuilder.build() .get() .uri("http://product-service/products") .retrieve() .bodyToMono(String.class) .block(); } } |
Each time you hit /get-products, it will hit a different instance of product-service in round-robin fashion.
π Default Load Balancing Strategy: Round Robin
Spring Cloud LoadBalancer uses RoundRobinLoadBalancer by default.
You can customize it by defining your own configuration.
βοΈ Custom LoadBalancer (Optional)
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 |
package com.kscodes.springboot.microservice.clientservice.config; import org.springframework.cloud.client.ServiceInstance; import org.springframework.cloud.client.loadbalancer.*; import org.springframework.context.annotation.Bean; import org.springframework.context.annotation.Configuration; import reactor.core.publisher.Mono; import java.util.List; import java.util.Random; @Configuration public class CustomLoadBalancerConfig { @Bean public ReactorServiceInstanceLoadBalancer customLoadBalancer(Environment environment, LoadBalancerClientFactory clientFactory) { String name = environment.getProperty(LoadBalancerClientFactory.PROPERTY_NAME); return new RandomLoadBalancer( clientFactory.getLazyProvider(name, ServiceInstanceListSupplier.class), name); } static class RandomLoadBalancer implements ReactorServiceInstanceLoadBalancer { private final ObjectProvider<ServiceInstanceListSupplier> serviceInstanceListSupplierProvider; private final String serviceId; private final Random random = new Random(); public RandomLoadBalancer(ObjectProvider<ServiceInstanceListSupplier> provider, String serviceId) { this.serviceInstanceListSupplierProvider = provider; this.serviceId = serviceId; } @Override public Mono<Response<ServiceInstance>> choose(Request request) { return serviceInstanceListSupplierProvider.getIfAvailable() .get() .next() .map(serviceInstances -> { if (serviceInstances.isEmpty()) { return new EmptyResponse(); } ServiceInstance instance = serviceInstances.get(random.nextInt(serviceInstances.size())); return new DefaultResponse(instance); }); } } } |
π§ͺ Testing Load Balancing
Start Eureka, product-service (2 instances), and client-service.
Hit:
|
1 2 3 |
http://localhost:8080/get-products |
Youβll see responses rotating between instance 1 (8081) and 2 (8082).
π§ Why Use Spring Cloud LoadBalancer?
- βοΈ Lightweight alternative to Ribbon
- π Supports reactive stack (WebClient)
- π Pluggable strategies (round-robin, random, zone-aware, etc.)
- π Compatible with service discovery tools (like Eureka)
π Conclusion
Using Spring Cloud LoadBalancer is the best way to achieve client-side load balancing in modern Spring-based microservice architectures. With native support for Eureka and WebClient, itβs lightweight, fast, and customizable.
Use the Spring Cloud LoadBalancer to improve your application’s availability and scalability, while avoiding unnecessary complexity.
