In a real-world Spring Boot application, it’s important to test how different components work together — services, controllers, repositories, and even security. This is where integration testing comes in, ensuring your application’s modules function as a cohesive unit.
Spring Boot simplifies integration testing with the powerful @SpringBootTest annotation. This guide will walk you through Spring Boot Integration Testing with @SpringBootTest, from configuration to writing meaningful test cases.
⚙️ What is @SpringBootTest?
@SpringBootTest tells Spring Boot to look for a main configuration class (e.g., one with @SpringBootApplication) and use that to start a full application context for the test.
This is ideal for:
- End-to-end tests
- Service + repository combinations
- Controller to DB flows
- Testing real HTTP requests
📦 Project Setup
Maven Dependencies:
Make sure the following dependencies are present in your pom.xml:
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 |
<dependencies> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-web</artifactId> </dependency> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-data-jpa</artifactId> </dependency> <dependency> <groupId>org.springframework.boot</groupId> <artifactId>spring-boot-starter-test</artifactId> <scope>test</scope> </dependency> <dependency> <groupId>com.h2database</groupId> <artifactId>h2</artifactId> <scope>test</scope> </dependency> </dependencies> |
📁 Sample Structure
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 |
com.kscodes.springboot ├── model │ └── Book.java ├── repository │ └── BookRepository.java ├── service │ └── BookService.java ├── controller │ └── BookController.java └── test └── integration └── BookIntegrationTest.java |
📘 Entity: Book
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 |
package com.kscodes.springboot.model; import jakarta.persistence.*; @Entity public class Book { @Id @GeneratedValue(strategy = GenerationType.IDENTITY) private Long id; private String title; private String author; // Getters and Setters } |
📚 Repository: BookRepository
|
1 2 3 4 5 6 7 8 9 |
package com.kscodes.springboot.repository; import com.kscodes.springboot.model.Book; import org.springframework.data.jpa.repository.JpaRepository; public interface BookRepository extends JpaRepository<Book, Long> {} |
🧠 Service: BookService
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 |
package com.kscodes.springboot.service; import com.kscodes.springboot.model.Book; import com.kscodes.springboot.repository.BookRepository; import org.springframework.stereotype.Service; import java.util.List; @Service public class BookService { private final BookRepository bookRepository; public BookService(BookRepository bookRepository) { this.bookRepository = bookRepository; } public List<Book> findAllBooks() { return bookRepository.findAll(); } } |
🌐 Controller: BookController
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 |
package com.kscodes.springboot.controller; import com.kscodes.springboot.model.Book; import com.kscodes.springboot.service.BookService; import org.springframework.web.bind.annotation.*; import java.util.List; @RestController @RequestMapping("/api/books") public class BookController { private final BookService bookService; public BookController(BookService bookService) { this.bookService = bookService; } @GetMapping public List<Book> getAllBooks() { return bookService.findAllBooks(); } } |
✅ Integration Test with @SpringBootTest
|
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 |
package com.kscodes.springboot.integration; import com.kscodes.springboot.model.Book; import com.kscodes.springboot.repository.BookRepository; import org.junit.jupiter.api.BeforeEach; import org.junit.jupiter.api.Test; import org.springframework.beans.factory.annotation.Autowired; import org.springframework.boot.test.context.SpringBootTest; import org.springframework.boot.test.web.client.TestRestTemplate; import org.springframework.boot.web.server.LocalServerPort; import java.util.List; import static org.assertj.core.api.Assertions.assertThat; @SpringBootTest(webEnvironment = SpringBootTest.WebEnvironment.RANDOM_PORT) public class BookIntegrationTest { @LocalServerPort private int port; @Autowired private BookRepository bookRepository; @Autowired private TestRestTemplate restTemplate; @BeforeEach void setUp() { bookRepository.deleteAll(); bookRepository.save(new Book(null, "Spring Boot Basics", "John Doe")); } @Test public void shouldReturnListOfBooks() { String url = "http://localhost:" + port + "/api/books"; Book[] response = restTemplate.getForObject(url, Book[].class); assertThat(response).hasSize(1); assertThat(response[0].getTitle()).isEqualTo("Spring Boot Basics"); } } |
🔎 Key Features of @SpringBootTest
| Feature | Description |
|---|---|
webEnvironment = RANDOM_PORT | Starts the embedded web server at a random port for HTTP testing |
@TestRestTemplate | Useful for sending real HTTP requests in tests |
| Full Spring Context | Loads beans, filters, configurations for realistic testing |
🧰 Best Practices
- Use
@SpringBootTestonly when you need full context. - For controller-only tests, prefer
@WebMvcTest. - Combine with Testcontainers if real DB testing is required.
- Use
@DirtiesContextif you want to reload context between tests (use cautiously). - Avoid mocking in
@SpringBootTestunless necessary — it’s meant for real integration.
📚 Summary
In this article, we explored Spring Boot Integration Testing with @SpringBootTest, including:
- When and why to use
@SpringBootTest - Setting up real HTTP-based tests using
TestRestTemplate - Testing controller-service-repository flow
- Best practices to keep tests fast and reliable
Spring Boot Integration Testing with @SpringBootTest helps you verify that all layers of your application work seamlessly together, ensuring confidence before deployment.
