Deploying Spring Boot on Google Cloud Platform

Google Cloud Platform (GCP) offers multiple managed and containerized solutions to deploy Spring Boot applications at scale. Whether you prefer App Engine (PaaS), Cloud Run (serverless), or GKE (Kubernetes), GCP has you covered.

In this post, we’ll cover three ways to deploy a Spring Boot app on GCP:

1. App Engine Standard
2. Cloud Run with Docker
3. Kubernetes Engine (GKE)

We’ll use com.kscodes.springboot.containers as our sample package for all examples.

🧰 Prerequisites

Before starting:

• A GCP project with billing enabled
• gcloud CLI installed and authenticated
• Docker installed (for Cloud Run and GKE)
• Maven or Gradle build system
• A basic Spring Boot app (.jar or Docker)

1️⃣ Deploying to App Engine Standard

App Engine is a fully managed platform. No infrastructure to manage—just deploy.

🛠️ Step 1: Prepare Your Spring Boot App

Ensure your app listens on port 8080:

package com.kscodes.springboot.containers;

import org.springframework.web.bind.annotation.GetMapping;
import org.springframework.web.bind.annotation.RestController;

@RestController
public class HelloController {
    @GetMapping("/")
    public String greet() {
        return "Hello from GCP App Engine!";
    }
}

📁 Step 2: Add app.yaml

# app.yaml
runtime: java21
instance_class: F1
env_variables:
  SPRING_PROFILES_ACTIVE: "gcp"

📦 Step 3: Deploy to App Engine

Package your app:

./mvnw clean package -DskipTests

Deploy:

gcloud app deploy target/*.jar

Visit:

gcloud app browse

2️⃣ Deploying to Cloud Run (Serverless Containers)

Cloud Run allows containerized apps to run with auto-scaling and pay-per-use pricing.

🐳 Step 1: Dockerfile

FROM eclipse-temurin:21-jdk
WORKDIR /app
COPY target/*.jar app.jar
EXPOSE 8080
ENTRYPOINT ["java", "-jar", "app.jar"]

⚙️ Step 2: Build and Push Container

gcloud builds submit --tag gcr.io/YOUR_PROJECT_ID/springboot-app

🚀 Step 3: Deploy to Cloud Run

gcloud run deploy springboot-service \
  --image gcr.io/YOUR_PROJECT_ID/springboot-app \
  --platform managed \
  --region us-central1 \
  --allow-unauthenticated

Access URL provided after deploy.

3️⃣ Deploying to Google Kubernetes Engine (GKE)

GKE gives full control over Kubernetes deployments.

🧱 Step 1: Enable GKE & Create Cluster

gcloud container clusters create springboot-cluster \
  --zone us-central1-a --num-nodes=2
gcloud container clusters get-credentials springboot-cluster --zone us-central1-a

🐳 Step 2: Docker Build and Push

docker build -t gcr.io/YOUR_PROJECT_ID/springboot-gke .
docker push gcr.io/YOUR_PROJECT_ID/springboot-gke

📄 Step 3: Kubernetes Deployment YAML

apiVersion: apps/v1
kind: Deployment
metadata:
  name: springboot-app
spec:
  replicas: 2
  selector:
    matchLabels:
      app: springboot
  template:
    metadata:
      labels:
        app: springboot
    spec:
      containers:
        - name: springboot
          image: gcr.io/YOUR_PROJECT_ID/springboot-gke
          ports:
            - containerPort: 8080

kubectl apply -f deployment.yaml

🌐 Step 4: Expose via LoadBalancer

apiVersion: v1
kind: Service
metadata:
  name: springboot-service
spec:
  type: LoadBalancer
  selector:
    app: springboot
  ports:
    - protocol: TCP
      port: 80
      targetPort: 8080

kubectl apply -f service.yaml
kubectl get service

⚖️ Which Option to Choose?

✅ Summary

In this tutorial, you learned how to deploy Spring Boot on Google Cloud Platform using App Engine, Cloud Run, and GKE. Each service offers a different trade-off between simplicity and control.

You now have three GCP-native ways to run your Spring Boot microservices in production with reliability and scalability.
