Backpressure in Spring WebFlux

Learn how Spring WebFlux handles backpressure to maintain responsiveness and prevent system overload in reactive applications.

📑 Table of Contents:

What is Backpressure?
Why Backpressure Matters in Reactive Systems
Reactive Streams and Backpressure
How WebFlux Handles Backpressure
Controlling Data Flow with Operators
Simulating a Slow Consumer
Tips for Optimizing Backpressure
Final Thoughts

🌊 1. What is Backpressure?

Backpressure refers to the mechanism that allows a subscriber to signal to the publisher that it can’t keep up with the data rate — essentially applying “back pressure” on the stream.

❓ 2. Why Backpressure Matters in Reactive Systems

Without backpressure:

Memory can overflow from unbounded queues
The system becomes unresponsive under load
You lose the benefits of non-blocking IO

Reactive systems must be resilient to slow consumers and high data throughput.

🔄 3. Reactive Streams and Backpressure

Reactive Streams specification supports backpressure natively.

In Reactor (used by WebFlux):

Mono handles backpressure implicitly (single item)
Flux honors demand via request(n)

When using Flux, you can request only N items at a time.

⚙️ 4. How WebFlux Handles Backpressure

WebFlux automatically:

Applies backpressure between layers (controller → service → repository)
Utilizes bounded elastic and parallel schedulers
Uses a reactive HTTP layer that communicates demand

Example:

@GetMapping("/events")

public Flux<String> streamEvents() {

return Flux.interval(Duration.ofMillis(100))

.map(i -> "Event " + i);

}

This will slow down if the subscriber can’t keep up.

🔧 5. Controlling Data Flow with Operators

🧰 Useful Operators:

limitRate(n) – Limits the request rate from the downstream
onBackpressureBuffer(n) – Buffers data when overwhelmed
onBackpressureDrop() – Drops data silently
onBackpressureLatest() – Keeps only the most recent item

Example:

Flux.range(1, 1000)

.onBackpressureBuffer(100)

.doOnNext(System.out::println)

.subscribe();

🧪 6. Simulating a Slow Consumer

Flux.interval(Duration.ofMillis(10))

.onBackpressureDrop()

.subscribe(i -> {

Thread.sleep(100); // Simulate slow subscriber

System.out.println("Received: " + i);

});

💡 7. Tips for Optimizing Backpressure

Avoid unbounded data sources
Use buffering or throttling operators wisely
Profile memory and CPU for large streams
Combine with retry + rate-limiting strategies

✅ 8. Final Thoughts

Backpressure is the heart of resilient reactive systems. Spring WebFlux offers seamless backpressure handling out of the box, but understanding how to apply buffering, dropping, or limiting strategies is key for production-grade applications.
